High Quality NEMA 11 Hybrid Screw Linear Stepper Motor 1.8 Degree 28mm

CHANGZHOU JKONGMOTOR CO.,LTD
Contact Now

High Quality NEMA 11 Hybrid Screw Linear Stepper Motor 1.8 Degree 28mm

Brand Name : Jkongmotor

Model Number : JK28HS51-0674PG5.18

Certification : CE, ROHS,ISO9001

Place of Origin : Jiangsu, China (Mainland)

MOQ : 3-10pcs

Price : US$5.5~US$35

Payment Terms : T/T , paypal , Western Union, L/C

Supply Ability : 100000pcs/month

Delivery Time : For samples , 7-15 days / For batch , 15-25days

Packaging Details : with export carton . big quantity with pallet

Name : stepper motor

Leads : 4

Current : 0.67A

Holding Torque : 1200g.cm

Step Angle : 1.8 degree

Shaft : 6mm

Phase Resistance : 9.2Ω

Phase Inductance : 7.2mH

voltage : 6.16v

phase : 2

Contact Now

High Quality 1.8 Degree 28mm NEMA 11 Hybrid Screw Linear Stepper Motor

Stepper motors are known for their accurate positioning capabilities and high torque delivery at low speeds, but they require careful sizing to ensure the motor matches the load and application parameters, to minimize the possibility of lost steps or motor stalling. Adding a gearbox to a stepper motor system can improve the motor’s performance by decreasing the load-to-motor inertia ratio, increasing torque to the load, and reducing motor oscillations.


1.Genaral Specification of stepper motors:

  • Step Angle(degrees): 1.8 Degree
  • Phase: 2
  • Type: Hybrid
  • Model Number: NEMA11
  • Model: JK28HS51-0674PG5.18
  • Holding Torque: 1200g.cm
  • Current / Phase: 0.67A
  • Motor length: 51mm
  • Diameter of axle: 6mm
  • Temperature rise: below 80 ℃
  • Ambient temperature: -20 ℃ ~ + 50 ℃
  • Insulation resistance: minimum 100MΩ, 500VDC
  • Dielectric strength: 500VAC for 1 minute
  • Shaft radial clearance: 0.02 max (450 g load)
  • Shaft axial clearance: 0.08Max. (450 g load)
  • Maximum radial force: 28N (20mm from flange)
  • Maximum axial force: 10N
  • size: Approximately 28x28x51mm


2.Electrical Specification of Nema11 stepper moror

Model No.

Step Angle

Motor Length

Current

/Phase

Resistance

/Phase

Inductance

/Phase

Holding Torque

# of Leads

Rotor Inertia

Motor

Weight

( °) (L)mm A Ω mH g.cm No. g.cmHigh Quality NEMA 11 Hybrid Screw Linear Stepper Motor 1.8 Degree 28mm Kg
JK28HS32-0674PG5.18 1.8 32 0.67 5.6 3.4 600 4 9 0.11
JK28HS45-0674PG51 1.8 45 0.67 6.8 4.9 950 4 12 0.14
JK28HS51-0674PG71 1.8 51 0.67 9.2 7.2 1200 4 18 0.2

3.Drawing of JK28HS51 step motor with encoder:
High Quality NEMA 11 Hybrid Screw Linear Stepper Motor 1.8 Degree 28mm

4.Produce equipment:

High Quality NEMA 11 Hybrid Screw Linear Stepper Motor 1.8 Degree 28mm

5.Production Process:
High Quality NEMA 11 Hybrid Screw Linear Stepper Motor 1.8 Degree 28mm

6.Advantages of hybrid Stepper Motor


The motor is simple in construction, reliable.
At the standstill condition, the motor has full torque.
The motors are less costly.
They require little maintenance.
The stepper motor has an excellent and accurate starting, stopping and reversing response.

High Quality NEMA 11 Hybrid Screw Linear Stepper Motor 1.8 Degree 28mmHigh Quality NEMA 11 Hybrid Screw Linear Stepper Motor 1.8 Degree 28mmHigh Quality NEMA 11 Hybrid Screw Linear Stepper Motor 1.8 Degree 28mmHigh Quality NEMA 11 Hybrid Screw Linear Stepper Motor 1.8 Degree 28mm
